Cylinder Sleeve Protrusion: 0 to +.008”, customer specified
Cylinder Head Fastening per Deck: (16) 7/16-14 studs & (2) 7/16 Bolt clearance holes. Standard pattern. Alternate fastening and pattern available at additional charge
Timing Drive(s): Jesel Belt Drive or RCD Gear Drive
Deck
Cam Heights
Main Size
Part Number
9.800"
+0.400
STD
200-908
10.200"
+0.400
STD
200-911
9.800"
+0.600
STD
200-900
10.200"
+0.600
STD
200-901
10.600"
+0.600
STD
200-902
Additional Information: Priority Main Oiling, Custom Rear Cam Plug, Wide DRCE Oil Pan Pattern, Dry Only, Custom lifter and head bolt patterns available upon request.
*Certain options are only available in some configurations. Please call to verify the combination you require is available*
For more information visit www.energymanufacturing.com
